FoxUn SX-HE07 H265/264 HDMI Encoder 1080P HDCP1.4

• The output supports RTSP / HLS / RTMP (S) / RTP / UDP protocol
• Support a variety of video decoding: H.265 mainstream, H.264 basic, mainstream and advanced quality, MJPEG/JPEG basic quality
• Audio coding format supports AAC, AAC+, AAC++
• Maximum support 2 channel video stream decoding, support 1 channel only audio stream decoding
• Support HDCP1.4
• HDMI IN resolution supports the maximum 1080P60Hz 4:4:4 8 bit with one loop out
• Support CBR/VBR two coding modes, maximum code rate up to 40Mbps (Main code stream is 40M, Sub-code stream is 8M)
• Support analog audio extraction and analog audio embedded
• DC 12V 1A, the maximum power consumption can’t over 4W

SX-HE07

21531
